FS10-R FSX Flame Detectors

Date:2017-10-20     Hits:3323

FS10-R

FSX Flame Detectors

A high-speed microprocessor based fire detection and process control system specially designed for liquid and powder coating applications, the FS System 10™ quickly detects the presence of a flame, reacts by initiating a shutdown of the electrostatic finishing process in a matter of milliseconds; and effectively interrupts the fire before residues and wet paint films can ignite.
Features & Benefits
Multi-spectral digital electro-optical infrared fire detector
Meets requirements of NFPA 33
Unique two-stage ALERT and FIRE ALARM response
Quick Specs
Immune to false alarms caused by arcs or corona discharges
Built-in automatic "through the lens" self-test

Not sensitive to background radiant energy sources such as paint heaters


Product Overview

FS System 10™
A high-speed microprocessor based fire detection and process control system specially designed for liquid and powder coating applications, the FS System 10™ quickly detects the presence of a flame, reacts by initiating a shutdown of the electrostatic finishing process in a matter of milliseconds; and effectively interrupts the fire before residues and wet paint films can ignite.

The FS System 10 is the only system that provides a two-stage response:
an ALERT for spray gun "fireball" type fires and if the fire continues, a FIRE ALARM is declared in 4-5 seconds.

The FS System 10 is vastly superior to conventional detectors due to the electro-optical quantum infrared sensors array and the ability to accurately detect fires without false alarms.The FS System 10 is available in both wall-mount controller and card controller configurations.(For additional information on card controller, consult the factory.)

The detector is mounted in an explosion-proof housing.The wall-mounted controller is a self-contained system mounted in a NEMA 12 enclosure with LCD display and LED status lights.Three 10-amp mechanical relays have been incorporated for shutting down the paint flow, electrostatics and conveyor.Event history and fire tech data are reported by the detector in real time and data, then stored in the controller’s non-volatile memory.FirePic™ and SnapShot™ data can be downloaded from the RS-232 port of the controller from your PC.The controller may operate with one or two detectors.

FS10-R Unitized
The FS10-R Unitized is a multi-spectral infrared electro-optical flame detector designed specifically for liquid paint or powder spray booth applications.
Based on the FS System 10, the FS10-R Unitized flame detector meets the need for a stand-alone capability and complies with the NFPA 33 Standard.
The WideBand IR™, NearBand IR, and Visible sensors combined with the advanced signal procession provide optimum performance.High spend fire response with optional factory sensitivity settings and alarm outputs provide the best, proven solution to fire detection for the Finishing Industry.

Additional Features and Benefits:

Multi-Spectral digital electro-optical infrared fire detector
Immune to false alarms caused by arcs or corona discharges
Built-in automatic "through the lens" self-test
Not sensitive to background radiant energy sources such as paint heaters
Not affected by absorbing smoke or paint solvent mist in liquid pant spray booths
Sees through paint, powder or oil residue on detector’s lens
Digital communications with RS-485 interface
FirePic™: retrieval of recorded pre-fire data
SnapShot™: dynamic graphical display of what the detector sees


Popular Accessories
From power options to carrying cases, we have a multitude of accessory items to go with your monitor.
SH-001
SH-001
Sunshield for SS2, SS4, FS24X and FS20X Detectors, 316 Stainless Steel.

SM4
SM4
Stainless Steel Swivel mounting assembly for FS24X, FS20X, SS4, SS2 detectors.


Fire Sentry FS10-R specifications
Multi-Spectral Electro-Optical
“Unitized”Flame Detector

General Specifications
Sensitivity 45 ft. and 30 ft. to a 1 sq. ft. gasoline fire*
Response Time Alert: 0.3 second (response to “fireball” type fires)
Fire Early Warning: 1 second (early response to a fire alarm)
Fire Alarm: Less than 5 seconds (if fire continues)
Field of View 90° (± 45° horizontal and vertical)
Spectral Sensitivity Visible: 400 – 700 nanometers
Near Band IR: 0.7 – 1.1 microns
Wide Band IR: 0.7 – 3.5 microns
Input Power 24 VDC nominal (18-32 VDC) - Regulated
Power Consumption Normal: 85 mA (typical); Alarm: 120 mA (typical)
Output Relays Alert/Early Warning: SPST, N.O.*
Fire Alarm: SPST, N.O.
Fault: SPST, N.O. with no power
Contact ratings: 1 amp @ 24 VDC
Normal Operation Fault relay is Energized, Non-Latching
All other relays are De-energized
Fire and Alert relays are available
Latching or Non-Latching
Operating Temperature Operating: -40º to +185ºF (-40º to +85ºC)
Humidity Range 10% to 90% relative humidity, non-condensing
Weight Aluminum: 3.8 lbs (1.7 kg)
Enclosure Copper-Free Powder Coated Aluminum or optional 316 Stainless Steel; NEMA 3, 4 and 4X
Conduit Entries Two ¾” NPT
Certifications Explosion-Proof; Class I, Div. 1 & 2, Groups B, C, & D
Class II, Div. 1 & 2, Groups E, F, & G
Class III
FM, CE
Dimensions 4.81 in. diameter; 4.65 in. deep
Mounting Swivel Bracket Assembly - Optional
Warranty Two years from date of shipping
* Detectors set at the 45-foot sensitivity setting do not have the Alert/Fire Early Warning output available.
